SM8L Molded Case Industrial Circuit Breaker 3 Pole 380V With Earth Leakage Protection

  • 1
  • 2
  • 3

Brand Name : FENIGAL/OEM

Model Number : SM8L

Certification : CE, CB, KEMA/Dekra etc.

Place of Origin : China

MOQ : 1 unit

Price : USD20~USD200

Payment Terms : T/T, Western Union

Supply Ability : 1,000pcs/month

Delivery Time : 5-8 working days

Packaging Details : Standard export carton

Product name : Mccb Moulded Case Circuit Breaker,Good quality 3 Pole tmax 100A mccb Molded Case Circuit Breaker,compact NS 800A 1000A 1250A 1600A mccb Molded Case Circuit Breaker

Rated voltage : 380V,380/400V,AC230/440/660,230/400V AC 50/60Hz

Rated current : 25,25,32,40,50,63,80,100,125,160,200,250,315,350,400,500,630A

Poles number : 3,4,3P 4P

Breaking capacity : 25-50kA

Material : Earthleakage protection

Installation : Fixed and Plug-in

Standard : IEC60947-2

Contact Now

FENIGAL/OEM



Features and Benefits

● Circuit breaker consists of electric leakage module, electronic mechanic release and zero-sequence current transformer;

● Residual current and leaking current delay time can adjust;

● Compact structure, easy for installation;

● The installation of circuit breaker are vertical installation and horizontal installation.



Specifications



Residual current release SM8L-110
Using technology Electronic
Operation With coil
Operating voltage(V) 50~500
Operating frequency(Hz) 50/60Hz ± 10%
Testing voltage range(V) 50~500
Rated operating current(A) Up to 250
Thershold value of trip I △ n(A) 0.03-0.1-0.3-0.5-3
Residual operation current allowances(%) +0,-20
Trip time(S) 0-0.1-0.25-0.5-1-1.5
Trip time allowanoce(%) ±20
Trip signal ●
Self-powered ●
Remote switch-off input ●
Alarm signal at 50% △ n ●
Only for Alternate current ●
Button of A used is AC ●
Low sensitivity ●
High sensitivity ●
Fixed under MCCB(vertically) ●
Fixed beside MCCB (plain way) ●
Dimension(L×H ×P)

120 × 120 ×70(RC212/2)ZLM1-160

140 × 170 × 108(RC212/3)ZLM1-250
Standard



releasing protection
IEC60947-2 appendix B

IEC255-4 and IEC1000:Defult



SM8L Molded Case Industrial Circuit Breaker 3 Pole 380V With Earth Leakage ProtectionSM8L Molded Case Industrial Circuit Breaker 3 Pole 380V With Earth Leakage Protection
